Epson SureColor SC-T3130N Wireless Technical Personal CAD Printer
FEATURES
High-speed, easy-to-use, compact 24" desktop inkjet printer.
-
Engineered to enhance the way you work, the 24" SureColor T3130N wide-format wireless printer offers fast, precise and reliable printing with a compact, clean desktop design. Ideal for printing blueprints, line drawings and posters up to 24", it produces accurate, A1/D-size prints in 34 seconds1. Whether you’re printing from a roll or the Auto Sheet Feeder, the 4.3" color touchscreen makes tasks simple and intuitive. Next-generation high-capacity UltraChrome®XD2 pigment inks deliver durable, vibrant prints. And, with integrated wireless and Wi-Fi Direct® connectivity2, you can easily print from tablets and smartphones3, from virtually anywhere in the office.
Specification
Printing
Printing Technology: PrecisionCore TFP PrintheadNozzle Configuration: 3200 nozzles (800 nozzles x 4 channels x 1head)Maximum Print Resolution: 2400 x 1200 dpiMinimum Ink Droplet Size: 4.0plPrint Speed: 34 Sec/A1 ; 106 A1/D per hour Minimum Line Width: Roll/Sheet Top, bottom, right, left : Min. 3mm (It differs depend on applications/media)
INK
Ink Type: Pigment ink(Epson UltraChrome XD2)Colours: Cyan, Magenta,Yellow, BlackInk Capacity: Black : 50ml , 80mlCyan, Magenta, Yellow : 26ml, 50mlInk Cartridge Configuration: Ink Cartridge
SHEET Handling
Maximum Paper Width: Roll 320mm-610 mm Cut sheet (ASF), A4-A3 Cut sheet ( 50 sheets )Left / Right Margins: 3 mm (left), 3 mm (right)Top/Bottom Margins: 3 mm (top), 3 mm (bottom)
ROLL Media Handling
Maximum Roll Diameter: SC-T3100 series (24") 2 inch coreMedia Width: 210mm-610mm RollMedia Thickness: Roll : 0.05 mm to 0.21 mmASF/Cutsheet : 0.12 mm to 0.27 mmRoll Paper Remaining: The remaining amount is managed on control panel.Roll Weight: 60 to 280 GSM ( Roll/manual feed ) . 60-230GSM ( input tray ) Auto-Cutter: Yes
Dimension
Display: 4.3 inch touch screenPrinter Language: ESC/P Raster, HP-GL/2 & HP RTL, Optional Adobe® Postscript® 3™Other Features: Dimension- Stowed : 970x696x913 mm ( w/stand ) , 970x505x230 mm (w/o stand )
Dimension- Printing : 970x982x913 mm( w/stand ) , 970x982x230 mm (w/o stand )Weight: 27 Kg (Without Stand)
PAPER Handling
Media Handling: Roll Paper: One Roll, Top-loading
Cut Sheet: Top-loading single sheet and front-loading single sheet for thick boardSupported Media Sizes: Roll Paper Width: 10" (254mm) to 24" (610mm)
Cut Sheet Width: A4 (210mm) to 24" (610mm)
Cut Sheet Length: 279.4mm to 1580mmPaper Weight: 60 to 280 GSM ( Roll/manual feed ) . 60-230GSM ( input tray ) , Paper Path: Friction FeedPaper Size & Thickness: Roll:329 mm - 610 mmCutsheet(ASF):A4 - A3Cutsheet(1 sheet): 210 mm - 610 mm* for ECC: Roll, Maximum width of loadable Roll media width is 620mm.But maximum width of Printing Area is 610mmRoll Paper Remaining: The remaining amount is managed on control panel.Media Thickness: Roll : 0.05 mm to 0.21 mmASF/Cutsheet : 0.12 mm to 0.27 mm
CONNECTIVITY
Interface: Super-Speed USB*, 100BASE-TX /1000BASE-T/IEEE802.11b/g/n (*Compatible with the USB 3.0 Specification.)Software to be Downloaded: WindiwsInstall NaviFirmware Updater, HDI Driver, CopyFactory, EpsonNet SetupManagerMacInstall Navi - Printer driver - EpsonNet Config - Eposn Software Updater - Uninstaller - EPSON manualsFirmware UpdaterLinuxPrinter driver
CONTENTS
- SureColor T3130N Printer
- Full Set of Initial Ink Cartridges (CMY – 26 mL/Black – 50 mL)
- Start Here Poster
- User Guide
- AC Power Cable
Warranty
- 1Year Epson India Warranty
- Brand New 100% Original Product
- GST Invoice
- Free Shipping.
